S-95072A302 1"-6 x 1 1/2" Fast-Travel Precision Acme Lead Screws and Nuts
Fast-Travel Precision Acme Lead Screws and Nuts
Image may differ from product. See technical specification for details.
Basic Information
Thread Parameters
Dimension Parameters
Lead Screw Specific Parameters
Nut Parameters
Load & Performance Parameters
- Fast delivery
- Enjoy discounts on bulk purchases
- Secure Payment
- Fast Global Shipping
Key Features & Benefits at a Glance
- Enhanced load-bearing performance with 5000 lbs dynamic thrust capacity for reliable operation in heavy-duty applications
- Superior wear resistance and longevity thanks to 360 Brass construction with Brinell 70 hardness
- Precision fast-travel capability delivering 0.333" linear movement per revolution for efficient positioning
- Optimized thread engagement with Class 2C fit ensuring smooth operation and reduced backlash
- Versatile dual-thread configuration featuring left-hand Acme internal threads and 1 3/8"-16 UN external threads
- Increased mechanical efficiency through 2:1 speed ratio for rapid motion transfer applications
- Robust external threading providing secure mounting and integration with existing systems
Professional Applications & Engineering Value
This 360 Brass Acme lead screw nut delivers exceptional engineering value in demanding industrial environments where precision motion control and high load capacity are critical. The combination of left-hand Acme threading and Class 2C thread fit ensures reliable performance in applications requiring reverse-thread functionality and minimal play. The Brinell 70 hardness provides superior resistance to deformation under continuous operation, while the 2:1 speed ratio enables rapid positioning in automation systems, CNC equipment, and material handling machinery. The externally threaded design with UN standard threads facilitates straightforward integration, making it ideal for precision lead screw assemblies where both internal and external threading requirements must be met simultaneously.
Specification Summary & Compliance
This precision component features Class 2C thread fit for Acme internal threads (1 1/2"-6) and standard UN external threads (1 3/8"-16), manufactured to exacting dimensional tolerances. The nut delivers consistent 0.333" travel per turn with left-hand thread direction and maintains 5000 lbs dynamic thrust load capacity. Constructed from 360 Brass with Brinell 70 hardness, this component meets industry standards for precision lead screw applications and is manufactured in compliance with RoHS and REACH environmental regulations.
